Name: 1/4" 3/8" 1/2" Drive Quick-Release Ratchet
Brand: Tool
SKU: 390
Availability: InStock

1/4″ 3/8″ 1/2″ Drive Quick-Release Ratchet

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

12 People watching this product now!

Best quick-release offset ratchets have optional drive sizes of 1/4″, 3/8″, 1/2″ with chrome vanadium steel construction and ergonomic TPR handle for durable and comfortable work. Offset handle gives fingers extra clearance. 1/4-in and 3/8-in 45 teeth design needs only 8 degree swing arc and 1/2-in 72 teeth design needs only 5 degree swing arc, as wel as reversible ratcheting mechanism, ideal ratcheting wrench for tight spaces. It is widely applied for automotive, construction, mechanical, home repair, and so on.

Specification

Model	T-YX041101	T-YX041102	T-YX041103
Drive Size	1/4 inch (6.3mm)	3/8 inch (10mm)	1/2 inch (12.5mm)
Measure Type	Metric
Material	Chrome vanadium steel (CR-V)
Finish	Polished chrome
Handle	Offset
Number of Teeth	45	45	72
Weight	165g	330g	530g

Applications

Tips: Ratchet handle introduction

The ratchet socket wrench is the most common socket wrench. The ratchet handle is a handle installed on the socket to turn the socket. If there is no matching handle, the socket will not work independently.

When using the ratchet, the socket wrench can be locked with a small turning angle and work in a limited space.

The head of the ratchet handle is designed with a ratchet device, which can realize rapid single-direction rotation without releasing the socket and bolt.

The rotation direction of the reversible ratchet can be changed by adjusting the locking mechanism. Turning the locking mechanism thumb to the left, you can tighten the bolt or nut clockwise in one direction; turning the locking mechanism handle to the right, you can loosen the bolt or nut in one direction counterclockwise.

The ratchet handle is easy to use but not strong enough. Do not use a ratchet wrench for the final tightening of the bolts or nuts. In addition, it is strictly forbidden to apply excessive torque to the ratchet handle, otherwise the internal pawl structure will be damaged.

When in use of a quick-release ratchet, press the quick-release button, put the socket head into the square drive of the ratchet wrench; release the button, the socket will be locked. If you press the button again, the socket can be released.
