10 Inch Compound Miter Saw with Belt, 7.5A/8A
Original price was: $327.54.$98.99Current price is: $98.99.
| Category | US | EU | UK | Chest (in) | Waist (in) | Hips (in) |
|---|---|---|---|---|---|---|
| Men | XS | 44 | 34 | 32-34 | 26-28 | 33-35 |
| S | 46 | 36 | 34-36 | 28-30 | 35-37 | |
| M | 48 | 38 | 38-40 | 32-34 | 39-41 | |
| L | 50 | 40 | 42-44 | 36-38 | 43-45 | |
| XL | 52 | 42 | 46-48 | 40-42 | 47-49 | |
| Women | XS | 32 | 6 | 31-32 | 24-25 | 33-34 |
| S | 34 | 8 | 33-34 | 26-27 | 35-36 | |
| M | 36 | 10 | 35-36 | 28-29 | 37-38 | |
| L | 38-40 | 12-14 | 37-39 | 30-32 | 39-41 | |
| XL | 42 | 16 | 40-42 | 33-35 | 42-44 | |
| Youth | XS | 128 | 7 | 26-28 | 23-24 | 26-28 |
| S | 134 | 8 | 28-30 | 24-25 | 28-30 | |
| M | 140 | 10 | 30-32 | 25-26 | 30-32 | |
| L | 146 | 12 | 32-34 | 26-27 | 32-34 | |
| XL | 152 | 14 | 34-36 | 27-28 | 34-36 |
| Category | US | EU | UK | Waist (in) | Hip (in) | Inseam (in) |
|---|---|---|---|---|---|---|
| Men | 28 | 44 | 28 | 28 | 34 | 30 |
| 30 | 46 | 30 | 30 | 36 | 31 | |
| 32 | 48 | 32 | 32 | 38 | 32 | |
| 34 | 50 | 34 | 34 | 40 | 33 | |
| 36 | 52 | 36 | 36 | 42 | 34 | |
| Women | 0 | 32 | 4 | 24 | 34 | 30 |
| 2 | 34 | 6 | 25 | 35 | 30 | |
| 4 | 36 | 8 | 26 | 36 | 31 | |
| 6 | 38 | 10 | 27 | 38 | 32 | |
| 8 | 40 | 12 | 28 | 40 | 32 |
| Category | US | EU | UK | Foot Length (in) |
|---|---|---|---|---|
| Men | 6 | 39 | 5.5 | 9.25 |
| 7 | 40 | 6.5 | 9.625 | |
| 8 | 41 | 7.5 | 10 | |
| 9 | 42 | 8.5 | 10.25 | |
| 10 | 43 | 9.5 | 10.625 | |
| 11 | 44 | 10.5 | 11 | |
| 12 | 45 | 11.5 | 11.25 | |
| 13 | 46 | 12.5 | 11.625 | |
| Women | 5 | 35 | 2.5 | 8.5 |
| 6 | 36 | 3.5 | 8.875 | |
| 7 | 37 | 4.5 | 9.25 | |
| 8 | 38 | 5.5 | 9.625 | |
| 9 | 39 | 6.5 | 10 | |
| 10 | 40 | 7.5 | 10.25 | |
| 11 | 41 | 8.5 | 10.625 | |
| 12 | 42 | 9.5 | 11 | |
| M (Unisex) | 5 | 37 | 4.5 | 8.75 |
| 6 | 38 | 5.5 | 9 | |
| 7 | 39 | 6.5 | 9.5 | |
| 8 | 40 | 7.5 | 10 | |
| 9 | 41 | 8.5 | 10.25 | |
| 10 | 42 | 9.5 | 10.625 | |
| 11 | 43 | 10.5 | 11 | |
| 12 | 44 | 11.5 | 11.25 |
Compound miter saw with belt for sale, it has a φ10 inch (255mm) saw blade, power supply is 240V or 220V. Applicable sawing materials are aluminum, wood, water pipe, steel pipe. It is a compact compound miter saw with good price.
Specification
| Model | T-XJX05-255 |
| Motor Power | 1,800W |
| Rated Voltage | 220V/50Hz, 240V/60Hz |
| Rated Current | 8.0A, 7.5A |
| Saw Blade Diameter | 10 inch (255mm) |
| Sawing Capacity | |
| 0°-0° Right Angle Positive Cutting | 78*85mm |
| 0°-45° Right Angle Bevel Cutting | 78*70mm |
| No-Load Speed | 5,500 rpm |
| Driving Mode | Belt Driven |
| Weight | 10.4 kg |
| Accessories | 1 saw blade, 1 Allen wrench, 1 dust collection bag |
Structure Diagram of Compound Miter Saw with Belt
Angle Adjustment Diagram
Saw Blade Installation for Compound Miter Saw with Belt
- Use a hexagonal screwdriver to open the saw blade screw.
- Remove the screws and fixed spacers.
- Install the saw blade.
- Install the screws.
- Tighten the screws.
- Adjust and complete.
Tips: What is a compound miter saw?
Compound miter saw is a power tool used for sawing aluminum, wood, steel and other materials. Compound miter saw enables saw blade and tool bit to be tilted at various angles to cut workpiece. It makes bevel cutting more convenient and faster. Miter cutting refers that cut diagonally into side of the material. Compound cut is a combination of miter cut and bevel cut.
Compound miter saw is recognized as the best tool for precise miter cutting on workpiece, whether the cut is square, angled or beveled. In many cases, Compound miter saws allow users to tilt and cut at the same time to complete precise and complex compound cutting.
