Name: 3 Ton Automotive Floor Jack, Low Profile
Brand: Tool
SKU: 997
Availability: InStock

3 Ton Automotive Floor Jack, Low Profile

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

56 People watching this product now!

3 ton automotive floor jack, low profile structure, hydraulic principle, 425mm lift height, CE/ GS/ TUV certification.

Specification:

Model	T-FLJ-E1103
Weight	30.5kg
Packing included	1 * floor jack 1 * safety bar 1 * tool box
Certification	CE, GS, TUV
Maximum capacity (car weight)	3 ton
Minimum height	75mm
Maximum height	500mm
Lift height	425mm
Size	780405190mm

Tips: How to use a floor jack?
The floor jack is a common lifting tool in auto repair shops. Its function is to lift the car to facilitate removing or replacing tires. Compared with the bottle jack, the floor jack is lower in height, and will be more stable after lifting, and will not cause unnecessary harm to the human body.
The usage of floor jack is as follows:

Find the support point. A place that is too fragile should never be used as a support point, which can easily damage the car chassis. For cars or SUVs, there is a fixed position where the floor jack head can be placed. It must not be placed under the car body shell.
After determining the support point, put the pressure rod into the casing in front of the jack, so that the jack can be pressed by the rod, and then the jack head will be rose.
After press the rod down continuously. In this way, the jack head will slowly rise through hydraulic action, until the car is pushed to a suitable height, and then stop applying pressure.
At this time, the car will be in a suspended state. The best way is to use spare tires or other objects under the car to prevent accidents caused by floor jack and car suddenly dumping. Then we can start to repair or inspect the car. Do not move the automotive floor jack during this period. After the repair is completed, the hydraulic jack needs to be relieved of pressure and then the car is gradually lowered back to its original position. Different brands of floor jacks have different pressure relief methods. Most of them will have a rotary switch, which can be turned counterclockwise to release the pressure and reset the floor jack.
After the pressure is relieved and reset, gently drag the floor jack out, then pull out the pressure rod, and arrange all the accessories and put them back in the jack tool box for next use.
