Name: Diamond Core Drill Machine, 200mm, 3650W
Brand: Tool
SKU: 714
Availability: InStock

Diamond Core Drill Machine, 200mm, 3650W

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

35 People watching this product now!

Concrete drilling machine with drill bit at low price, free shipping, features 3650 watt electric power, 700 r/min working speed, 15-205mm drilling diameter, vertical use, wet/dry double use and comfortable, convenient and tireless operation are available during working.

Description

Model Number	T-205E
Power Source	electrical power
Drill Type	wet / dry dual use
Drilling Range	15-205mm (3/5-8 inch)
Max. Drilling Diameter	205mm (8 inch)
Rated Voltage	110V / 220V / 240V
Rated Frequency	50-60Hz
Rated Input Power	3650W
No-load Speed	0-700 r/min
Dimensions	335240900mm
Characteristics	vertical
Net Weight / Gross Weight	22kg / 25.8kg
Certification	CE
Package	single item
Package Size	335 * 240 * 900mm
Package Type	large carton box
Application	reinforced concrete, rocks, ceramics, glass and fire-proof materials

Features

Advantages: Wet/dry dual use diamond core drill features rig-mounted drilling system and uses bulit-in and outside adjustable friction clutch and is designed with soft starting as well as overcurrent protection so it is characterized by flexible mobility, economy and durablity, safety and reliability.
Application: Diamond core drilling machine is a new tool which can be used to drill holes on reinforced concrete, rocks, ceramics, glass and fire-proof materials, is widely used in construction quality inspection, airport runway construction, building installation, the installation of water, electricity, heat and gas and contruction of railway, bridges and tunnel.

Details

Power Plug Selection

(Note: Power plug can be customized based on your local machine standards.)

Tips: Some inspection work that needs to be done before drilling

1. Keep work area clean, bright and safe. Messy and dark areas may lead to accidents.
2. Do not operate the diamond core drill machine in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools can creat sparks which may ignite the dust or flumes.
3. Always focus on the drilling task and do not let other things like people and animals distract you to lose control of the handy machine.
4. Do not operate the core drill in bad weather, such as dense fog, heavy rain, strong wind and intense cold, otherwise it will cause some serious accidents.
5. Cordon off the area and make sure that no one appear and there are no other barriers. Always check the rear side of the surface where the drill bit will emerge when the machine is drilling.
