Name: Inflatable Air Blower, 380/480/680/750W
Brand: Tool
SKU: 1108
Availability: InStock

Inflatable Air Blower, 380/480/680/750W

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

37 People watching this product now!

This high-performance inflatable air blower features a 380W, 480W, 680W, or 750W motor, delivering powerful and consistent airflow. Designed for use with 220-240V or 110-120V power supply, it offers a compact and lightweight build, low operating noise, and a durable plastic housing. Easy to transport and highly reliable, it’s ideal for inflating bounce houses, bouncy castles, water slides, and other inflatable attractions.

Features

With a powerful, efficient motor, the air blower can produce more airflow.
Convenient top-mounted handle design, easy to transport or carry.
With reliable reinforced plastic housing and high-quality metal fan impellers, low noise and high durability.
Air intake/outlet is covered with a protective screen to keep impurities out effectively.
Cheap yet reliable air blower pump is suitable for home and commercial bounce houses, bouncy castles, water slides, obstacle courses, jumpers, and other inflatable games, and also great for advertising and promotional inflatables such as arches and mascots.

Specification

Model	T-J-2E/S-3E	T-J-3E	T-J-4E-1	T-S-7/S-7E
Power	380 Watt	480 Watt	680 Watt	750 Watt / 1 hp
Voltage	220-240V 50Hz or 110-120V 60Hz	220-240V 50Hz or 110-120V 60Hz	220-240V 50Hz or 110-120V 60Hz	220-240V 50Hz or 110-120V 60Hz
Speed	2800 rpm	2800 rpm	2800 rpm	2850 rpm
Pressure	1600 Pa	1650 Pa	1750 Pa	1750 Pa
Air Flow	650 m3/h (670 CFM)	750 m3/h (740 CFM)	1200 m3/h	1250 m3/h
Power Cord Length	2m	2m	4m	4m
Material	PE engineering plastic housing	PE engineering plastic housing	PE engineering plastic housing	PE engineering plastic housing
Waterproof Grade	IPX4	IPX4	IPX4	IPX4
Certification	CE, UL	CE, UL	CE, UL	CE, UL
Dimension	440280445 mm	440280445 mm	490310470 mm	490310470 mm
Net Weight/ Gross Weight	8kg/ 15kg	8kg/ 15	10kg/ 17kg	10kg/ 17kg

Note: * The inflatable air blower with 50Hz voltage is NOT suitable for use with 60Hz power supply.

Video – ATO Inflatable Air Blower Overview

Applications

Tips: Working Principle of Centrifugal Blower

The centrifugal blower operates on a similar principle to a centrifugal fan, but it typically utilizes multiple impellers or stages to compress the air under centrifugal force. The blower consists of a high-speed rotating rotor with blades that accelerate the air. The centrifugal force causes the air to flow along an involute path toward the fan’s outlet, generating high-speed airflow with pressure. Meanwhile, fresh air is drawn in from the center of the casing to maintain a continuous supply.
