Pin Moisture Meter for Grain
Original price was: $222.23.$66.99Current price is: $66.99.
| Category | US | EU | UK | Chest (in) | Waist (in) | Hips (in) |
|---|---|---|---|---|---|---|
| Men | XS | 44 | 34 | 32-34 | 26-28 | 33-35 |
| S | 46 | 36 | 34-36 | 28-30 | 35-37 | |
| M | 48 | 38 | 38-40 | 32-34 | 39-41 | |
| L | 50 | 40 | 42-44 | 36-38 | 43-45 | |
| XL | 52 | 42 | 46-48 | 40-42 | 47-49 | |
| Women | XS | 32 | 6 | 31-32 | 24-25 | 33-34 |
| S | 34 | 8 | 33-34 | 26-27 | 35-36 | |
| M | 36 | 10 | 35-36 | 28-29 | 37-38 | |
| L | 38-40 | 12-14 | 37-39 | 30-32 | 39-41 | |
| XL | 42 | 16 | 40-42 | 33-35 | 42-44 | |
| Youth | XS | 128 | 7 | 26-28 | 23-24 | 26-28 |
| S | 134 | 8 | 28-30 | 24-25 | 28-30 | |
| M | 140 | 10 | 30-32 | 25-26 | 30-32 | |
| L | 146 | 12 | 32-34 | 26-27 | 32-34 | |
| XL | 152 | 14 | 34-36 | 27-28 | 34-36 |
| Category | US | EU | UK | Waist (in) | Hip (in) | Inseam (in) |
|---|---|---|---|---|---|---|
| Men | 28 | 44 | 28 | 28 | 34 | 30 |
| 30 | 46 | 30 | 30 | 36 | 31 | |
| 32 | 48 | 32 | 32 | 38 | 32 | |
| 34 | 50 | 34 | 34 | 40 | 33 | |
| 36 | 52 | 36 | 36 | 42 | 34 | |
| Women | 0 | 32 | 4 | 24 | 34 | 30 |
| 2 | 34 | 6 | 25 | 35 | 30 | |
| 4 | 36 | 8 | 26 | 36 | 31 | |
| 6 | 38 | 10 | 27 | 38 | 32 | |
| 8 | 40 | 12 | 28 | 40 | 32 |
| Category | US | EU | UK | Foot Length (in) |
|---|---|---|---|---|
| Men | 6 | 39 | 5.5 | 9.25 |
| 7 | 40 | 6.5 | 9.625 | |
| 8 | 41 | 7.5 | 10 | |
| 9 | 42 | 8.5 | 10.25 | |
| 10 | 43 | 9.5 | 10.625 | |
| 11 | 44 | 10.5 | 11 | |
| 12 | 45 | 11.5 | 11.25 | |
| 13 | 46 | 12.5 | 11.625 | |
| Women | 5 | 35 | 2.5 | 8.5 |
| 6 | 36 | 3.5 | 8.875 | |
| 7 | 37 | 4.5 | 9.25 | |
| 8 | 38 | 5.5 | 9.625 | |
| 9 | 39 | 6.5 | 10 | |
| 10 | 40 | 7.5 | 10.25 | |
| 11 | 41 | 8.5 | 10.625 | |
| 12 | 42 | 9.5 | 11 | |
| M (Unisex) | 5 | 37 | 4.5 | 8.75 |
| 6 | 38 | 5.5 | 9 | |
| 7 | 39 | 6.5 | 9.5 | |
| 8 | 40 | 7.5 | 10 | |
| 9 | 41 | 8.5 | 10.25 | |
| 10 | 42 | 9.5 | 10.625 | |
| 11 | 43 | 10.5 | 11 | |
| 12 | 44 | 11.5 | 11.25 |
The pin moisture meter for grain has a 4-digit LCD display, measuring 3% to 80% for general files and 6% to 30% for special files. It offers 0.1 µm resolution, works in 5% to 90% humidity, and 0℃ to 60℃, with ±0.5% accuracy. Powered by 4 AAA batteries, it uses electrical resistance and automatic temperature compensation for accuracy.
Specification
| Model | T-MM-TK25G |
| Display | 4 Digital LCD |
| Measuring Range | 3~80% (general file), 6~30% (special file) |
| Resolution | 0.1 µm |
| Humidity | 5%-90% |
| Temperature | 0-60℃ |
| Accuracy | ±0.5% |
| Power Supply | 4×1.5 AAA Size (UM-4) Battery |
| Operation | Electrical resistance method, automatic temperature compensation |
| Dimensions | 460mm x 75mm x 35mm |
| Weight | 203g (Not Including Battery) |
Feature
- Backlit LCD Display: The portable grain moisture meter features a clear, backlit LCD display with low power consumption for easy reading.
- Microprocessor Control: Equipped with microprocessor control, the meter offers built-in automatic protection measures for enhanced stability.
- Wide Working Range: The meter supports a wide working range, with a probe-type sensor designed for in-depth material measurement.
- Battery-Powered: Powered by 4 No.7 batteries, the grain moisture detector ensures convenience and portability during use.
Application
Tips: What maintenance does the Pin Moisture Meter for Grain require?
To maintain the accuracy and longevity of your moisture meter, it’s important to keep the pins clean and dry. After each use, wipe the pins with a soft cloth to remove any residue or grain particles. Store the device in a protective case when not in use to prevent damage to the pins or display. Additionally, remove the batteries if the meter won’t be used for an extended period to prevent battery leakage. Regular maintenance will ensure the device stays in good working condition for years to come.
