Name: Wall Chaser Grooving Machine, 4000W, 115mm
Brand: Tool
SKU: 681
Availability: InStock

Wall Chaser Grooving Machine, 4000W, 115mm

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

17 People watching this product now!

4000 watt wall chaser grooving machine for sales, is a powerful construction tool widely used to making cuts for the installation of conduits, place the cables for electrical systems and for the installation of pipes for hydraulic systems. It’s powered by 50Hz 220V electric motor, 115mm (4.5″) saw blade diameter, 7500 rpm working speed.

Description

Model	T-120-1
Saw Type	circular saw
Voltage	220V AC
Power	4000W
Saw Blade Diameter	115mm (4.5″)
No-load Speed	7500(rpm)
Max. Cutting Depth	37mm (1.5″)
Cutting Depth	37mm (1.5″)
Cutting Width	33mm (1.3″)
Net Weight / Gross Weight	4.5kg (9.9 pounds) / 7.0kg (15.4 pounds)
Package	115mm saw blade * 5 + 3m water pipe * 1 + water pump * 1+ suitcase * 1 + vacuum cleaner adapter * 1
Packing Size	700 * 250 * 300mm
Application	red brick, granite, concrete, marble, rebar

Features

Adjustable cutting depth & wedth: Cutting groove depth of wall chaser can be randomly controlled. Max. cutting depth is up to 37mm (1.5″), max. cutting width 33mm (1.3″).
Easy to hold: Weight 4.5kg, the handle can be rotated 360°. It can also work much effort without any assistants to increase the efficiency of work.
Safety: With high power 4000W copper motor and power supply voltage 220V; the two devices of vacuum cleaner and water pump work at the same time to reduce the dust during work, taking into account your health; the switch is equipped with a waterproof cover. Protect the power supply from leakage & protect you from harm.
Multifunction use: Widely applied and adapt to different materials of wall, such as red brick, granite, concrete, marble, rebar. Ideal for electricians, plumbers and other contractors.

Notes: User should take dustproof glasses, mask and built-in vacuum port and water pump at the same time to reduce the dust during work.

Size

Details

Tips: How to install saw blades of wall chaser grooving machine?

Step 1. Use wrench to fix the main shaft and use the hex wrench to turn counterclockwise to loosen it.
Step 2. Insert the pressure plate.
Step 3. Place the saw blade and pressure plate at intervals.
Step 4. Place the nut on the pressure plate.
Step 5. Tighten the screw with the wrench and hex.
Step 6. The saw blades are installed.
