6000 lbs Hydraulic Winch for Tractor/Truck/Skid Steer

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

47 People watching this product now!

With a rope speed range of 0-40 m/min, this hydraulic winch is ideal for various industrial tasks, from vehicle recovery to equipment positioning. Powered by a hydraulic system, it ensures consistent force and operational safety, making it an essential addition to any heavy machinery setup needing dependable pulling performance.

Specification

Model		T-HW30-30
The 1st Layer	Pull	6000 lbs (3 ton)
	Rope Speed	0~35 m/min
Working Pressure Differential		17 Mpa
Oil Flow Supply		75 L/min
Rope Diameter		12mm
Hydraulic Motor		BMR-305
Planetary Reduction Ratio		1:5

Layer		Wire Rope Capacity
1		18m
2		38m
3		59m
4		80m
5		110m

Note: Never exceed working load limit.

Dimensions (Unit: mm)

Tips: How to Use a Hydraulic Winch Safely and Effectively

Using a hydraulic winch requires attention to safety and operational guidelines for efficient performance. Here’s a step-by-step guide:

Preparation
Inspect the winch, hydraulic lines, and attachments for any visible wear or damage.
Check the hydraulic fluid levels and ensure the winch is securely mounted to the vehicle or equipment.
Connect the Cable
Attach the cable or rope to the load securely using appropriate hooks or shackles.
Make sure the load is within the winch’s weight capacity to avoid strain or damage.
Control Panel Operation
Start the hydraulic system on your vehicle or equipment.
Use the control panel or lever to engage the winch. Hydraulic winches often have precise control for adjusting speed and tension.
Winching Process
Slowly reel in or let out the cable, maintaining steady pressure. Keep an eye on the load to ensure it remains stable and does not shift.
Avoid sudden movements, which could lead to jerks and strain on the winch or load.
Stopping and Disengagement
Once the load is in place, release the hydraulic pressure gradually and lock the winch if necessary.
Disconnect the cable carefully and store it properly to prevent wear or tangling.
Post-Operation Inspection
Inspect the winch, hydraulic system, and cables after use. This helps maintain longevity and ensures safe operation next time.
