Cheap electric screwdriver for sale, powered by brushless motor. It is the best power screwdriver for low torque adjusting applications (0.15-1.5 kgf). Small size and high precision.

Electric Screwdriver Specification

Model		T-GA-0.5	T-GA-1.0	T-GA-1.5
Input Voltage		DC 22V
Torque Range	kgf.cm	0.15-0.5	0.2-1.0	0.3-1.5
	lbf.in	0.130-0.434	0.174-0.868	0.260-1.302
	N.m	0.015-0.049	0.020-0.098	0.029-0.147
Torque Accuracy		±0.1%
Torque Adjustment		stepless
Torque Adjustment Mode		internal debugging
Start Method		hand press/downward press
No-load Speed		500-1000rpm
No-load Current		0.15A
Weight		92g
Applicable Bit		φ4
Applicable Screw Diameter (mm)	Mechanical Tooth	1.0-1.5	1.0-2.0	1.0-2.0
	Self-tacking Tooth	1.0-1.4	1.0-1.7	1.0-1.7

Power Controller Specification

Input Voltage	AC 100V-250V
Output Voltage	22V
Output Current	0.8A
External Dimension	955337mm
Weight	60g

Features

The brushless electric screwdriver uses pen-type hand-held design, lightweight and impact-resistant. It can freely lock screws 360°.
Adjustable torque, accurate torque setting and high precision.
Brushless electric screwdriver is built-in magnetic induction stop device, high sensitivity. Instantaneous braking, low impact force, not easy to damage.
Power adapter provides dual voltage 110V~250V working environment, convenient and safe to use.

Brushless Electric Screwdriver Dimension Drawing

Torque Curve Diagram

Tips: How to avoid brushless electric screwdriver failure?

Be careful not to bump or drop the brushless electric screwdriver, and it is strictly forbidden to hit it, otherwise it will cause motor noise and screwdriver shaking.
When unplugging the connection plug of brushless electric screwdriver and power controller, take the plug base as force point. Do not pull the wire forcefully to avoid damage to connection plug.
If brushless electric screwdriver shakes too much when working, it must be stopped and repaired in time.
If the torque of brushless electric screwdriver is too small to meet requirements, stop using it and replace the electric screwdriver with high torque in time.
When press power button, if the brushless electric screwdriver cannot be turned due to too little torque, this situation should be controlled within 10 seconds to avoid damage to the internal motor.
