Name: Digital Crane Weighing Scale 1 ton/2 ton/3 ton/5 ton/10 ton
Brand: Tool
SKU: 1364
Availability: InStock

Digital Crane Weighing Scale 1 ton/2 ton/3 ton/5 ton/10 ton

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

10 People watching this product now!

Digital crane scales are highly accurate and robust industrial equipment widely used in scenarios such as manufacturing, logistics, warehousing and construction industries. The series of weighing scales offer a wide range of weighing capacities such as 1 ton, 2 tons, 3 tons, 5 tons and 10 tons, which can meet the weighing needs of different weight items. This hanging scales utilize advanced high-precision sensing technology to ensure the accuracy of weighing results and are equipped with high-definition digital displays for easy and intuitive operation. Optional wireless data transmission function is available to facilitate data transmission to terminal equipment for management. Built-in high-capacity rechargeable battery provides long battery life and is suitable for outdoor or unpowered environments. The durability and versatility of the digital crane scales make them ideal for industrial weighing, and they excel in all types of application scenarios.

Specification

Model	T-CS-OCS-P
Capacity	1 ton	2 ton	3 ton	5 ton	10 ton
Sensor Material	Alloy steel
Display Size	1.2 inches
Product Material	Aluminum alloy shell
Weight	11kg			13.5kg	20kg
Weighing Range	1t/200g	2t/500g	3t/500g	5t/1kg	10t/2kg
Display	Red light display (indoor)/green light display (outdoor)
Units	Kg/Lb
Power Supply Type	AC/DC
Input	AC100-240V 50/60Hz
Output	DC8.5V-1000MA
Battery of Crane Scale	6V lead-acid battery alternating current

Features

Remote wireless control
Two display options
Strong bearing capacity
Multiple units
Built in large capacity battery charging/plug in
High strength large lifting ring

Crane scale dimension (cm)

(Note: The above data are measured manually. In case of any error please refer to the actual object.)

Tips: How does the digital crane weighing scale work so accurantely?

Digital crane weighing scales ensure accurate measurements through a combination of advanced sensor technology, precise signal processing, and real-time data display. The core component of these scales is the high-precision sensor, often a strain gauge sensor, which detects the force applied by the suspended load. When an object is lifted, the sensor measures the mechanical stress or strain caused by the weight and converts this force into an electrical signal. This initial conversion is crucial for maintaining accuracy.

Once the electrical signal is generated, it undergoes amplification and conversion within the scale’s electronic system. The system processes the raw electrical signal, calibrating it to account for various factors such as load distribution and environmental conditions. This processing ensures that the digital representation of the weight is precise and reliable. The electronic system then translates the processed signal into digital data, which is displayed on a digital screen, providing the user with an accurate readout of the object’s weight.

In addition to real-time display, many digital crane weighing scales come with features for data storage and wireless transmission. These capabilities allow users to record weight measurements and transfer the data to computers or other devices for analysis. Regular calibration and maintenance are essential to uphold the scale’s accuracy and performance. This combination of precise sensors, advanced signal processing, and data management ensures that digital crane weighing scales provide reliable and accurate measurements.
