This handheld laser rangefinder not only supports a maximum measuring distance of 120 meters, but also has advanced features such as self-calibration, plus or minus area volume calculation, and time delay measurement, which perfectly meets the complex measurement needs. Its laser is class 2, with a wavelength of 630-670nm and a power of less than 1mW, which is safe and reliable. The large LCD screen with backlight design allows clear reading of data even in low-light environments.

Specification

Model	T-SW-DS50	T-SW-DS70	T-SW-DS100	T-SW-DS120
Measuring Distance	50m	70m	100m	120m
Distance Measurement Accuracy	± (1.5mm+d*5 parts per hundred thousand)
Continuous Measurement Function	Yes
Area Volume Measurement	Yes
Trigonometry Function	Yes
Angle and Height Measurement	Yes
Addition and Subtraction Measurement Function	Yes
Adding or Subtracting Area and Volume	Yes
Max/Min	Yes
Time-delay Measuring Function	Yes
Self-calibration	Yes
Laser Class	Ⅱ
Laser Type	Level 2, 630-670nm, <1mW
Number of Stored Records	99 strokes
Auto Cut-off Laser	20 sec
Auto Power-off	150 seconds
Full Charge Operating Time	8000 strokes
Sound Alert (can be turned off)	Yes
Storage Temperature Range	-20℃~60℃
Operating Temperature Range	0℃~40℃
Storage Humidity	20%~80%RH
Battery Specifications	2×1.5V AAA Battery
Inclination Measurement Range	± 90°
External Dimensions	1125025mm
Net Weight	210g

ATTENTION: “D” indicates the actual distance.

** In harsh environment, such as: strong sunlight, excessivelyfluctuated ambient temperature, weak reflection effect of theobject’s surface and the low battery, a large error will occur inmeasurement results, so a reflecting plate is needed.

Handheld Laser Distance Meter Dimension (unit: mm)

Handheld Laser Distance Meter Deatail

Bluetooth Laser Distance Meter Multiple Measurement Methods

Tips: What are the scenarios for which handheld laser rangefinders are suitable?

Handheld laser rangefinders are widely used in architecture, interior design, engineering surveying, real estate and other fields. It is especially suitable for scenes that require fast and accurate distance measurement, such as measuring the height of a house, the length of a wall, or performing area and volume calculations. It is also a handy tool for measuring terrain and distance when working outdoors, which is easy to carry and simple to use.
