1/4 Ton Electric Chain Hoist
Price range: $154.99 through $213.62
Size chart
| Category | US | EU | UK | Chest (in) | Waist (in) | Hips (in) |
|---|---|---|---|---|---|---|
| Men | XS | 44 | 34 | 32-34 | 26-28 | 33-35 |
| S | 46 | 36 | 34-36 | 28-30 | 35-37 | |
| M | 48 | 38 | 38-40 | 32-34 | 39-41 | |
| L | 50 | 40 | 42-44 | 36-38 | 43-45 | |
| XL | 52 | 42 | 46-48 | 40-42 | 47-49 | |
| Women | XS | 32 | 6 | 31-32 | 24-25 | 33-34 |
| S | 34 | 8 | 33-34 | 26-27 | 35-36 | |
| M | 36 | 10 | 35-36 | 28-29 | 37-38 | |
| L | 38-40 | 12-14 | 37-39 | 30-32 | 39-41 | |
| XL | 42 | 16 | 40-42 | 33-35 | 42-44 | |
| Youth | XS | 128 | 7 | 26-28 | 23-24 | 26-28 |
| S | 134 | 8 | 28-30 | 24-25 | 28-30 | |
| M | 140 | 10 | 30-32 | 25-26 | 30-32 | |
| L | 146 | 12 | 32-34 | 26-27 | 32-34 | |
| XL | 152 | 14 | 34-36 | 27-28 | 34-36 |
| Category | US | EU | UK | Waist (in) | Hip (in) | Inseam (in) |
|---|---|---|---|---|---|---|
| Men | 28 | 44 | 28 | 28 | 34 | 30 |
| 30 | 46 | 30 | 30 | 36 | 31 | |
| 32 | 48 | 32 | 32 | 38 | 32 | |
| 34 | 50 | 34 | 34 | 40 | 33 | |
| 36 | 52 | 36 | 36 | 42 | 34 | |
| Women | 0 | 32 | 4 | 24 | 34 | 30 |
| 2 | 34 | 6 | 25 | 35 | 30 | |
| 4 | 36 | 8 | 26 | 36 | 31 | |
| 6 | 38 | 10 | 27 | 38 | 32 | |
| 8 | 40 | 12 | 28 | 40 | 32 |
| Category | US | EU | UK | Foot Length (in) |
|---|---|---|---|---|
| Men | 6 | 39 | 5.5 | 9.25 |
| 7 | 40 | 6.5 | 9.625 | |
| 8 | 41 | 7.5 | 10 | |
| 9 | 42 | 8.5 | 10.25 | |
| 10 | 43 | 9.5 | 10.625 | |
| 11 | 44 | 10.5 | 11 | |
| 12 | 45 | 11.5 | 11.25 | |
| 13 | 46 | 12.5 | 11.625 | |
| Women | 5 | 35 | 2.5 | 8.5 |
| 6 | 36 | 3.5 | 8.875 | |
| 7 | 37 | 4.5 | 9.25 | |
| 8 | 38 | 5.5 | 9.625 | |
| 9 | 39 | 6.5 | 10 | |
| 10 | 40 | 7.5 | 10.25 | |
| 11 | 41 | 8.5 | 10.625 | |
| 12 | 42 | 9.5 | 11 | |
| M (Unisex) | 5 | 37 | 4.5 | 8.75 |
| 6 | 38 | 5.5 | 9 | |
| 7 | 39 | 6.5 | 9.5 | |
| 8 | 40 | 7.5 | 10 | |
| 9 | 41 | 8.5 | 10.25 | |
| 10 | 42 | 9.5 | 10.625 | |
| 11 | 43 | 10.5 | 11 | |
| 12 | 44 | 11.5 | 11.25 |
32
People watching this product now!
Description
Best and cheap electric chain hoist with 1/4 ton (250kg) capacity, 3-phase 400V operation voltage fits perfectly with that of the industry standard, alternative voltages are available. Because of stable load, This electric chain fall can be widely used in transport, construction, and other areas for lifting goods, and also ideal for portable use in workshops, garages, factory.
Specification
| Model | T-SSDHL-0.2501S |
| Speed Type | Single speed |
| Capacity | 1/4 ton |
| Lifting Speed | 23.5 FPM (7.2 m/min) |
| Motor Power | 0.8 kW |
| Rotation Speed | 1440 r/min |
| Standard Lifting Length | 3m, contact us for other length |
| Protection Grade | IP54 |
| Insulation Grade | F |
| Power Supply | 3 phase 220V/ 230V/ 240V/ 380V/ 400V/ 415V/ 480V (Optional) |
| Control Voltage | 24V/ 36V/ 48V (Optional) |
| No. of Chain | 1 |
| Diameter of Load Chain | 6.3 mm |
| Net Weight / Gross Weight | 45 kg / 55 kg |
Features
- Shell: Electric chain hoist made of aluminum alloy shell, light but hard. It is fit for the use in the terrible work environment with a high heat dissipation rate and all tightness design.
- Limit switch: The limit switch device of electric chain hoist is installed where the weight is lifted on and off to make the motor to stop automatically so as to prohibit the chains from exceeding for safety.
- Chain: The chain adopts the FEC80 ultra heat-treatable aluminum alloy chain, can be used in poor invironment.
- Hook: The hook of electric chain hoist is hot forging with perfect strength that is hard to break. The operation safety of the lower hook is ensured by its 360 degrees rotation and safety tongue piece.
- Side magnetic braking device: The magnetic force generator is the latest design which is featured for generating magnetic force. It allows instant brake as soon as the electric power is cut off. Thus the braking safety while loading is guaranteed.
Dimension
H: 480mm, A: 400mm, B: 210mm, D: 258mm, E: 170mm
Tips: Why should lubricate the parts of electric chain hoist?
One of the important links in the maintenance of electric chain hoist is the lubrication of parts. If the lubrication measures are done well, it will not only prevent rust, but also prolong the service life of the electric hoist. The main benefits of lubrication are as follows:
- Lubrication: It can reduce the number of electric chain hoist systems and turn dry friction into wet friction.
- Anti-corrosion effect: The lubricating grease itself has no corrosive effect on the equipment, and it has the effect of isolating moisture in the air and other harmful impurities. At the same time, it can also neutralize excessive acids, alkalis and other corrosive impurities during electric chain fall operation.
- Damping effect: The electric chain hoist inevitably produces vibration during operation, but due to the existence of the lubricating oil film, the mechanical energy generated by the vibration is absorbed by the oil film and converted into internal frictional heat, thereby eliminating the energy of mechanical vibration through the friction of the liquid, so that the lifting tool runs smoothly.
