2000 lbs Hydraulic Winch for Tractor/Truck/Skid Steer

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

18 People watching this product now!

Powered by hydraulic systems, it is designed for use with tractors, skid steers, rollback trucks, and excavators, providing reliable performance in demanding work environments. Ideal for various heavy-duty applications, this winch combines strength, speed, and durability at a competitive price.

Specification

Model		T-HW05-10
The 1st Layer	Pull	2000 lbs (1 ton)
	Rope Speed	0~45 m/min
Working Pressure Differential		11 Mpa
Oil Flow Supply		56 L/min
Rope Diameter		8mm
Hydraulic Motor		BMR-125
Planetary Reduction Ratio		1:5.23

Layer		Wire Rope Capacity
1		10m
2		21m
3		33m
4		45m

Note: Never exceed working load limit.

Dimensions (Unit: mm)

Tips: Hydraulic Winch Working Principle

Hydraulic Power Source: A hydraulic winch is powered by hydraulic fluid from a pump, typically integrated with machines like tractors, trucks, or excavators. The fluid pressure generates the force needed to rotate the winch drum.
Planetary Gear Reduction: The winch uses a planetary gear system to reduce the speed while increasing torque, allowing the winch to handle heavy loads with ease. The reduction ratio determines how much force is applied to the load.
Control System: Hydraulic winches come with control valves to regulate the flow of hydraulic fluid, enabling smooth and precise operation. The operator can control the lifting or pulling speed based on the task requirements.
Brake System: A built-in brake system ensures load security by holding the load in place when the operation stops, preventing accidents or slippage.
Safety Mechanism: Safety features such as overload protection and automatic shutoff ensure the winch stops functioning if the load exceeds its capacity, protecting both the equipment and operators.

By understanding these principles, you can operate a hydraulic winch more efficiently and safely in various applications.
