Name: 45&#176; Portable Deburring Chamfering Machine
Brand: Tool
SKU: 39
Availability: InStock

45° Portable Deburring Chamfering Machine

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

30 People watching this product now!

The portable machine is an electric chamfering tool combines chamfering and deburring functions in one, chamfering range is 15°~45°, small size and convenient for use.

Specification

Model	T-CFM-R200	T-CFM-R200A
Chamfering Range	0~3 (6) mm	0~9mm
Chamfering Angle	15°~45°	15°~45°
Rated Voltage	380V	380V
Motor Power	250W	750W
Speed	2800rpm	3000~6000rpm
Dimension	382424.5cm	382424.5cm
Warranty	1 year	1 year
Weight	13 kg	13 kg

Application: The portable deburring/chamfering machine is suitable for large workpieces of any length, unheated and not easily moved, such as chamfering in the manufacturing process of various molds and mechanical parts. In addition, it is also suitable for batch processing of small workpieces, deburring for metal pipes, metal plates, molds, and mold frames, and manufacturing of mechanical equipment and hardware parts, etc.

Portable Deburring/Chamfering Machine Structure Diagram

Accessories

Chamfering Demonstration

When operating, hold the slide rail against workpiece and cut in the direction indicated by arrow.

Tips: How to ensure safety when operating portable deburring/chamfering machine?

Before starting, check whether the protective cover of chamfering machine is intact and fastened. Check whether tool movement direction and workbench feed direction are correct.
When starting to work, fix the workpiece on sucker workbench with both hands, and then start cutting. According to length of the workpiece, control foot switch.
If milling tool is passivated, stop machine to replace the blade, and pay attention to retreat the tool before stopping. When stopping, stop blade feeding first, then stop the spindle.
It is strictly forbidden to touch tool tip and iron filings by hand when working. Use an air gun (or brush) to remove chips on machine bed surface and milling cutter. When removing chips, stop the machine.
During work, it is strictly forbidden to touch the rotating spindle, workpiece or other moving parts by hand or in any other way.
