Name: Combination Wrench, 12-Point, 6mm/8mm/15mm to 32mm
Brand: Tool
SKU: 444
Availability: InStock

Combination Wrench, 12-Point, 6mm/8mm/15mm to 32mm

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

45 People watching this product now!

Features

Buy Combination Wrench or Combination Spanner in metric sizes, optional 6mm, 8mm, 9mm, 10mm, 18mm,… 28mm, 30mm, 32mm.
Hardened chrome vanadium steel structure with chrome-polished provides long use time and rust & corrosion protection.
12-point box end doubles the access angles of a 6-point for precise and fast working with fasteners.
The combination wrench features a 10-degree offset on the box end for easy and comfortable use at work.

Specification

Model	T-LYBS-0632
Material	Chrome vanadium steel (CR-V)
Finish	Chrome polished
Measure Type	Metric
Size (Optional)	6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm, 20mm, 21mm, 22mm, 23mm, 24mm, 25mm, 26mm, 28mm, 30mm, 32mm
Weight	See below

Dimension Drawing

Size (mm)	Overall Length (mm)	Open End Thickness (mm)	Box End Thickness (mm)	Weight (g)
6	100	4.5	5.5	18
7	110	5.0	6.0	24
8	120	5.3	6.5	33
9	130	5.7	6.7	40
10	142	6.5	7.5	58
11	152	6.5	6.9	58
12	161	6.5	7.3	64
13	171	6.9	8.5	88
14	182	7.5	8.3	97
15	191	7.6	8.5	111
16	201	8.5	9.7	149
17	210	8.3	9.5	155
18	221	8.3	10.3	175
19	231	8.3	10.9	193
20	230	8.3	10.3	169
21	255	9.3	11.5	236
22	270	9.0	12.3	264
23	267	8.9	11.7	245
24	287	10.0	12.7	306
25	287	9.7	12.5	282
26	320	10.0	12.7	395
28	320	10.3	13.7	414
30	335	11.0	14.9	559
32	355	9.9	13.3	520

Note: The sizes are approximate.

Tips: Basics of combination wrench

The combination wrench is a common type of wrenches or spanners. Since it has one end of the same as the single-head open end spanner and the other end of the same as the box spanner, it has two different functions.

Combination wrenches are different from open wrenches in that they can be fastened and removed with screws on both sides, except that one side is open end and the other side is box end. Wrenches like this are designed to combine the advantages of both types of wrenches and have tremendous advantages in some parts handling.

There are two sizes of combination wrenches: metric and Imperial. The common Metric combination wrenches cover 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, 18mm, 19mm, etc and the Standard combination wrenches have 1/4″, 5/16″, 11/32″, 3/8″, 7/16″, 1/2″, 9/16″, 5/8″, 11/16″, 3/4″, 13/16″, 7/8″, 15/16″, 1″ and so on.

In terms of function, combination wrenches are more commonly used than other wrenches and are required in many processing industries. It is widely used in petroleum, chemical industry, metallurgy, power generation, oil refining, shipbuilding, petrochemical and other industries. It is a necessary tool for equipment installation, installation and equipment overhaul and maintenance.
