26 People watching this product now!

Built for harsh off-road use, this motorcycle hour meter is IP68 waterproof, shock-resistant, and protected against mud, rain, and pressure washing. Its heat-resistant sensor cable 200℃ ensures durability. A true motocross hour meter and best hour meter for dirt bike, it provides accurate DC hour meter runtime for ATVs, generators, lawn mowers, and chainsaws, all in a waterproof hour meter package.

Specification

Model	T-ZSB-03
Power Supply	DC 3V (internal high-capacity battery)
Total Hour Range	0 – 99999 hours (non-resettable)
RPM Range	0 – 30000 RPM
Measurement Accuracy	±1%
Resolution	0.1 (RPM)
Display Type	LCD
Installation	Inductive (wrap wire around spark plug cable)
Waterproof Rating	IP68 (fully waterproof)
Battery Life	≥3 years
Operating Temperature	-10℃ to +60℃
Dimensions	175.2 × 98.7 × 16.8 mm
Weight	68g

Features

Non-resettable total hour counter: Digital hour meter records engine runtime up to 99,999 hours. The total cannot be reset, making it a reliable dirt bike hour meter and the best hour meter for dirt bikes for maintaining accurate service schedules and resale value.
High range tachometer: Measures engine speed from 0 to 30,000 RPM with ±1 percent accuracy and 0.1 resolution. Perfect as a motocross hour meter or DC hour meter for tuning 2-stroke and 4-stroke engines.
Inductive installation: Wrap the 200 Celsius rated sensor wire 3 to 6 turns around the spark plug cable. No cutting or tapping into the motorcycle electrical system is required, making installing a non-resettable hour meter on the dirt bike quick and tool-free.
IP68 waterproof and shockproof: Fully sealed housing protects the dirt bike hour meter from rain, mud, and pressure washing. This waterproof hour meter is perfect for motocross and outdoor off-road use.
Long-life DC 3V battery: Built-in high-capacity battery delivers three years or more of operation. No external power needed, making
motorcycle hour meter portable and suitable for dirt bike hour meter, hour meter for generator, go karts, ATVs, jet skis, and boats.
Heat-resistant wiring: Sensor cable rated for 200 Celsius, epoxy-potted electronics ensure reliable performance in engine compartments.

Dimension (Unit: mm)

Applications

Digital hour meter for dirt bikes and motorcycles is the best hour meter for off-road vehicles, ATVs, and motocross bikes. It also works perfectly on generators, lawn mowers, chainsaws, agricultural machinery, and any gasoline-powered engine requiring accurate runtime tracking.

FAQs

Q: How to install a digital DC hour meter on a dirt bike?
A: Wrap the inductive sensor wire around the spark plug cable 3-6 turns, secure with the included zip tie, and mount the waterproof hour meter on a clean surface using double-sided tape or zip ties. No cutting or splicing required.
Q: Is DC hour meter really suitable for off-road use?
A: Yes, it is IP68 waterproof and shock-resistant, making it the best hour meter for dirt bikes in mud, rain, and even pressure washing conditions.
Q: Can I use the same hour meter for generators or lawn mowers?
A: Absolutely. This digital DC hour meter works on any gasoline engine with a spark plug, including generators, lawn mowers, chainsaws, and agricultural machinery.
Q: What is the RPM range of motorcycle hour meter?
A: The tachometer measures from 0 to 30,000 RPM with ±1% accuracy, providing real?time engine speed for tuning and performance monitoring.
