The electric sharpener is the best grinder for drill bits grinding and sharpening. Attachment of the drill sharpening machine is CBN or SDC grinding wheel (optional).
Specification
| Model | T-DBSG-26A | T-DBSG-G3 |
| Grinding Range (mm) | Φ13-Φ26 | Φ3-Φ26 |
| Point Angle | 95°~135° | 95°~135° |
| Power | 220V 50/60Hz | |
| Motor | 250W | |
| Rotation Speed | 4,400 rpm | |
| Grinding Wheel | CBN (Special for high speed steel) or SDC (Special for tungsten steel) | |
| Dimension (cm) | 49*25*16 | 40*28*33 |
| Weight | 29.5kg | 34kg |
Features
| T-DBSG-26A |
|
| T-DBSG-G3 |
|
Drill Bit Sharpener Grinder Structure Diagram
| T-DBSG-26A |
| T-DBSG-G3 |
Drill Bit Sharpener Grinder Grinding Effect Diagram
Drill Bit Sharpener Grinder Attachments List
|
|
Attachments | Quantity | |
| T-DBSG-26A | T-DBSG-G3 | ||
| 1. SDC/CBN grinding wheel | 1 | 1 | |
| 2. ER Collet | 14 | 24 | |
| 3. Small Allen wrench | 3 | 3 | |
| 4. Chuck set | 1 | 2 | |
Tips: Use drill bit sharpener grinder to grind the front cutting lip.
When using the drill bit sharpener grinder grinding the front cutting lip, put chuck fixture set into the static point grinding seat. Gently push the bottom grinding wheel, put drill bit in the bottom, and rotate it to the right until there is no grinding sound. Back to the center again, take out fixture and turn 180°. Grind the other side of drill bit in the same way until there is no grinding sound.
Note: When taking chuck fixture set up and down, align the locating pin on the grinding seat at the approximate center of missing corner line on chuck fixture set.
