Oval Gear Flow Meter for Oil, DN10-DN200
Price range: $89.99 through $10,451.76
| Category | US | EU | UK | Chest (in) | Waist (in) | Hips (in) |
|---|---|---|---|---|---|---|
| Men | XS | 44 | 34 | 32-34 | 26-28 | 33-35 |
| S | 46 | 36 | 34-36 | 28-30 | 35-37 | |
| M | 48 | 38 | 38-40 | 32-34 | 39-41 | |
| L | 50 | 40 | 42-44 | 36-38 | 43-45 | |
| XL | 52 | 42 | 46-48 | 40-42 | 47-49 | |
| Women | XS | 32 | 6 | 31-32 | 24-25 | 33-34 |
| S | 34 | 8 | 33-34 | 26-27 | 35-36 | |
| M | 36 | 10 | 35-36 | 28-29 | 37-38 | |
| L | 38-40 | 12-14 | 37-39 | 30-32 | 39-41 | |
| XL | 42 | 16 | 40-42 | 33-35 | 42-44 | |
| Youth | XS | 128 | 7 | 26-28 | 23-24 | 26-28 |
| S | 134 | 8 | 28-30 | 24-25 | 28-30 | |
| M | 140 | 10 | 30-32 | 25-26 | 30-32 | |
| L | 146 | 12 | 32-34 | 26-27 | 32-34 | |
| XL | 152 | 14 | 34-36 | 27-28 | 34-36 |
| Category | US | EU | UK | Waist (in) | Hip (in) | Inseam (in) |
|---|---|---|---|---|---|---|
| Men | 28 | 44 | 28 | 28 | 34 | 30 |
| 30 | 46 | 30 | 30 | 36 | 31 | |
| 32 | 48 | 32 | 32 | 38 | 32 | |
| 34 | 50 | 34 | 34 | 40 | 33 | |
| 36 | 52 | 36 | 36 | 42 | 34 | |
| Women | 0 | 32 | 4 | 24 | 34 | 30 |
| 2 | 34 | 6 | 25 | 35 | 30 | |
| 4 | 36 | 8 | 26 | 36 | 31 | |
| 6 | 38 | 10 | 27 | 38 | 32 | |
| 8 | 40 | 12 | 28 | 40 | 32 |
| Category | US | EU | UK | Foot Length (in) |
|---|---|---|---|---|
| Men | 6 | 39 | 5.5 | 9.25 |
| 7 | 40 | 6.5 | 9.625 | |
| 8 | 41 | 7.5 | 10 | |
| 9 | 42 | 8.5 | 10.25 | |
| 10 | 43 | 9.5 | 10.625 | |
| 11 | 44 | 10.5 | 11 | |
| 12 | 45 | 11.5 | 11.25 | |
| 13 | 46 | 12.5 | 11.625 | |
| Women | 5 | 35 | 2.5 | 8.5 |
| 6 | 36 | 3.5 | 8.875 | |
| 7 | 37 | 4.5 | 9.25 | |
| 8 | 38 | 5.5 | 9.625 | |
| 9 | 39 | 6.5 | 10 | |
| 10 | 40 | 7.5 | 10.25 | |
| 11 | 41 | 8.5 | 10.625 | |
| 12 | 42 | 9.5 | 11 | |
| M (Unisex) | 5 | 37 | 4.5 | 8.75 |
| 6 | 38 | 5.5 | 9 | |
| 7 | 39 | 6.5 | 9.5 | |
| 8 | 40 | 7.5 | 10 | |
| 9 | 41 | 8.5 | 10.25 | |
| 10 | 42 | 9.5 | 10.625 | |
| 11 | 43 | 10.5 | 11 | |
| 12 | 44 | 11.5 | 11.25 |
Choose this oval gear flow meter for oil and you’ll get a well-designed flow meter that’s easy to install. Available in port sizes from DN10 to DN200, it is suitable for measuring a wide range of oils, including diesel oil and gasoline. Its on-site display return-to-zero function and pointer flow display make operation intuitive and efficient. The meter supports a variety of output signals, including pulse, 4-20 mA and RS485, for flexible adaptation to different monitoring systems.
Specification
| Model | T-LC-E |
| Display | Pointer single time, cumulative intelligent liquid crystal display |
| Output Signal | Output of pulse, 4-20 mA output, RS485 |
| Return to Zero | Optional |
| Measurement Medium | Diesel oil, gasoline |
| Port Size | DN10-200 |
| Measurement Range | 0.04-340 m3/h |
| Accuracy | 0.5 grade, 0.2 grade |
| Medium Temperature | 20 ℃ ~ 100 ℃ |
| Working Pressure | 106 Mpa, 25 Mpa, 6.4 Mpa |
| Working Temperature | 30 ℃ ~ 80 ℃ |
| Power Supply | DC 12V ~ DC 24V |
| Protection Level | IP65 |
| Explosion Proof Grade | CT6 |
| Material | Cast iron, cast steel, stainless steel |
Oval Gear Flow Meter for Oil Dimension: (Unit: mm)
| DN | L | H | B | C | I | D | D1 | N | φ |
| 10 | 150 | 100 | 210 | 120 | 45 | 90 | 60 | 4 | 14 |
| 15 | 170 | 118 | 226 | 136 | 48 | 95 | 65 | 4 | 14 |
| 50 | 200 | 150 | 238 | 148 | 53 | 105 | 75 | 4 | 14 |
| 25 | 260 | 180 | 246 | 156 | 60 | 115 | 85 | 4 | 14 |
| 40 | 245 | 180 | 271 | 181 | 77 | 145 | 10 | 4 | 18 |
| 100 | 515 | 418 | 458 | 278 | 131 | 215 | 180 | 8 | 18 |
| 150 | 540 | 515 | 557 | 377 | 210 | 280 | 240 | 8 | 23 |
| 200 | 650 | 650 | 624 | 444 | 247 | 335 | 295 | 12 | 23 |
Oval Gear Flow Meter for Oil Features
- Oval gear flow meters are designed to be simple, quick to install and easy to maintain with no complicated adjustments required.
- The meter is equipped with an on-site zero function, making it easy for users to reset and recalibrate the meter.
- Intuitive flow rate display clearly shows the real-time flow rate, which is convenient for accurate monitoring and recording.
- Adopting multi-process machining, fine craftsmanship, sturdy structure and superior pressure resistance.
Oval Gear Flow Meter Applications
Tips: How to maintain and clean an oval gear flow meter?
Regular maintenance and cleaning of oval gear flowmeters is essential to ensure their long-term stable operation. First, periodically check the flowmeter for oil buildup or clogging with contaminants, especially in applications with high viscosity oils or those containing solid particles. To clean, turn off the flowmeter and disassemble the flowmeter components, washing all parts in contact with oil with an appropriate solvent. Ensure thorough drying before reassembling. Also, inspect and replace worn seals and gears to prevent oil leaks. Follow the maintenance manual provided by the manufacturer to extend the life of the flow meter.
