Rotary Hammer with SDS Drill, 1000W, 32mm

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

46 People watching this product now!

Rotary hammer not only has the function of electric hammer, but also can be used as power drill and electric pick. 1kW high power, drilling capacity is φ32mm (1-1/4 inch). SDS drill bits are included in accessories.

Specification

Model	T-RTHM-8032A
Drilling Diameter	32mm
Function	hammering, drilling, demolition
Voltage	230V
Frequency	50Hz
Rated Power	1,000W
No-load Speed	800rpm
Hammering Rate	4200bpm
Impact Energy	7.2J
Weight	5.2kg
Standard Accessories	3 SDS drill hammer bits (8, 10, 12*150mm), ruler, carbon brush, dust cover, tool box

Features

3 functions can be switched. Electric drill function for drilling of metal, wood, ceramics, etc. Electric hammer function for breaking in wall demolition, engineering construction, interior decoration. Electric pick function for demolition in wall slotting, ground chiseling, trench wiring, etc.
Pure copper motor provides high power, stable and efficient, low noise, high speed.
Spiral-type heat dissipation system, dissipate heat quickly and prevent the machine from burning out.

Rotary Hammer Structure Diagram

Hammer Bit Installation

Screw the four-pit adapter handle into the adapter chuck.
Put in fastening screws and tighten them.
Insert the four-pit adapter handle into the rotary hammer chuck. Align the short groove to round steel ball. Insert hammer bit down. When hearing a click, installation is completed.
Put in hammer bit and fix it with chuck. After adjusting the concentricity, use chuck key to tighten the 3 holes on the side in turn.

Tips: What checks should be done before using rotary hammer?

Check the hammer bit.
A dull or bent hammer bit will overload the motor and reduce work efficiency. Therefore, the old hammer head should be replaced in time.
Check the fixing screws on rotary hammer body.
As the rotary hammer generates impact when it is running, it is easy to loosen the mounting screws on body. Therefore, check the tightening condition frequently. If it found that screws are loose, re-tighten it immediately, otherwise rotary hammer will malfunction.
Check carbon brushes.
The carbon brush on motor is a consumable. Once the degree of wear exceeds its limit, motor will malfunction. Therefore, the worn out carbon brushes should be replaced in time and keep the carbon brushes clean.
Check the protective grounding wire.
Protective grounding wire is an important measure to protect personal safety, so it should be checked frequently to ensure that the shell of rotary hammer is well grounded.
Check the dust cover.
Dust cover can prevent dust from entering the internal mechanism of rotary hammer. If the inside of dust cover is worn out, it should be replaced immediately.
