Name: 0.01-3mm Metric Feeler Gauge, 45 Blades
Brand: Tool
SKU: 1399
Availability: InStock

0.01-3mm Metric Feeler Gauge, 45 Blades

Size chart

Clothing Size Conversion Chart
Category	US	EU	UK	Chest (in)	Waist (in)	Hips (in)
Men	XS	44	34	32-34	26-28	33-35
	S	46	36	34-36	28-30	35-37
	M	48	38	38-40	32-34	39-41
	L	50	40	42-44	36-38	43-45
	XL	52	42	46-48	40-42	47-49
Women	XS	32	6	31-32	24-25	33-34
	S	34	8	33-34	26-27	35-36
	M	36	10	35-36	28-29	37-38
	L	38-40	12-14	37-39	30-32	39-41
	XL	42	16	40-42	33-35	42-44
Youth	XS	128	7	26-28	23-24	26-28
	S	134	8	28-30	24-25	28-30
	M	140	10	30-32	25-26	30-32
	L	146	12	32-34	26-27	32-34
	XL	152	14	34-36	27-28	34-36

Pants Size Conversion Chart
Category	US	EU	UK	Waist (in)	Hip (in)	Inseam (in)
Men	28	44	28	28	34	30
	30	46	30	30	36	31
	32	48	32	32	38	32
	34	50	34	34	40	33
	36	52	36	36	42	34
Women	0	32	4	24	34	30
	2	34	6	25	35	30
	4	36	8	26	36	31
	6	38	10	27	38	32
	8	40	12	28	40	32

Shoes Size Conversion Chart
Category	US	EU	UK	Foot Length (in)
Men	6	39	5.5	9.25
	7	40	6.5	9.625
	8	41	7.5	10
	9	42	8.5	10.25
	10	43	9.5	10.625
	11	44	10.5	11
	12	45	11.5	11.25
	13	46	12.5	11.625
Women	5	35	2.5	8.5
	6	36	3.5	8.875
	7	37	4.5	9.25
	8	38	5.5	9.625
	9	39	6.5	10
	10	40	7.5	10.25
	11	41	8.5	10.625
	12	42	9.5	11
M (Unisex)	5	37	4.5	8.75
	6	38	5.5	9
	7	39	6.5	9.5
	8	40	7.5	10
	9	41	8.5	10.25
	10	42	9.5	10.625
	11	43	10.5	11
	12	44	11.5	11.25

18 People watching this product now!

Precision metric feeler gauge with a 0.01-3mm range. This 45-blade feeler gauge features a tapered design for easy access to tight spaces.

Features

Overall metallic texture with fine polishing, burr-free, and smooth to the touch.
High hardness, accurate measurements, good elasticity, and no damage to products or machines.
The feeler gauge surface is coated with anti-rust oil, ensuring smooth expansion without sticking.
360° fan-shaped rotating design for easy storage.
Detachable individual blades with screw tightness adjustment for flexibility.

Specification

Model: T-FG-100B45
Measuring Range: 0.01-3mm
Combination of Blades:0.01, 0.02, 0.03, 0.04, 0.05, 0.06, 0.07, 0.08, 0.09, 0.10, 0.11, 0.12, 0.13, 0.14, 0.15, 0.16, 0.17, 0.18, 0.19, 0.20, 0.21, 0.22, 0.23, 0.24, 0.25, 0.28, 0.30, 0.35, 0.40, 0.45, 0.50, 0.55, 0.60, 0.70, 0.75, 0.80, 0.85, 0.90, 0.95, 1.0, 1.1, 1.2, 1.4, 1.5, 1.8, 2.0, 3.0
Blade Length: 100mm
Material: Spring Alloy Steel (65Mn)
Weight: 1kg

Dimension(Units:mm)

Application

Tips: Precautions for Using a Feeler Gauge

Do not bend the feeler gauge excessively or force it into the gap being measured with excessive force during the measurement process. This could damage the measuring surface of the feeler gauge or compromise the precision of the component’s surface.
After use, clean the feeler gauge thoroughly, apply anti-rust oil, and fold it back into the holder to prevent rust, bending, deformation, or damage.
When storing the feeler gauge, avoid placing it under heavy objects to prevent damage.
